TimeZero Professional

SKU: ms206006

TimeZero Professional is a professional plotter with all the necessary functions for navigation and fishing. The solution features full BarentsWatch integration, an outstanding weather forecast presentation with long-term predictions, and an overview of oceanographic data. It is integrable with Furuno radar, echo sounder, multibeam echo sounder, and sonar. Easy import of data from other chart systems.

Feature-rich integration platform for navigation and fisheries

  • Full BarentsWatch integration
  • Compatible with all Furuno DRS network radar models
  • Compatible with all Furuno echo sounder modules, as well as FCV-1150 and WASSP
  • Professional 2D/3D bottom visualization
  • High-resolution bottom hardness presentation
  • Logbook and extensive historical data presentation
  • Easy import of data from other chart systems



FLEXIBLE INTEGRATION PLATFORM

TimeZero Professional has become a popular solution for a variety of service vessels and for all types of fishing vessels. At the core of the system are the electronic charts, offering unique display capabilities and a wide selection of color palettes.

What makes TimeZero Professional so versatile are the many integration options with other Furuno instruments for navigation, communication, surveying, and fish detection.

SCALABLE SOLUTION

Thanks to its integration capabilities, TimeZero Professional is a highly scalable solution that can be adapted to the needs of any vessel. For small vessels with limited bridge space, it is often desirable to display charts, integrated radar, and integrated echo sounder on a single screen. Larger vessels, on the other hand, often prefer to display the charts and integrated instruments on dedicated screens via a matrix setup. Either way, TimeZero Professional can be configured to suit your needs.

TimeZero Professional is an award-winning plotter with all the functionality needed for navigation and fisheries. The solution includes full BarentsWatch integration, a 3D depth database, and personalized bottom mapping (PBG). Integration with WASSP also makes the system suitable for various types of survey operations.



TIMEZERO V5 IS NOW AVAILABLE

TimeZero Professional V5 introduces a range of new features, including the Smart Radar function, which enhances situational awareness and promotes safer navigation.

ENIX PRO – A NEW SERIES OF MARITIME MONITORS

Hatteland ENIX PRO series is a line of maritime displays developed through close collaboration between Hatteland and Furuno Norge. These high-quality monitors are built to withstand onboard indoor conditions, including vibration, varying humidity, light, and temperature.

Hatteland ENIX PRO series series is CE-certified and suitable for equipment not requiring type-approved monitors, making them ideal for use with TimeZero Professional and integrated instruments.

ENIX PRO displays offer a broad range of ports for connectivity. The larger monitors support various layouts like split, quad and others. All models in the ENIX PRO series are high-definition LED displays, with resolutions up to 4K depending on the model. Touchscreen functionality and a remote controller for power, menu navigation, brightness, and dimming are also available.

ENIX_skjermer_hatteland_modeller


OVERVIEW OF TIMEZERO PROFESSIONAL ADD-ON LICENSES



TimeZero Professional offers a wide selection of modules, allowing you to build the system that best suits your fishing operations. Licenses are required to access the modules.

Subscriptions

  • TimeZero Oceanic  - Weather data (1/3/6/12 month(s))
  • TimeZero Oceanio  -  Oceanographic data (1/3/6/12 month(s))

> CONTACT US ABOUT ADD-ON LICENSES





OVERVIEW OF COMPATIBLE FURUNO INSTRUMENTS



Radars and Network Radars

  • Radar FAR-2xx8 series
  • Radar FAR-1518
  • Radar FAR-1513

  • Network Radar DRS 12A NXT
  • Network Radar DRS 6A NXT
  • Network Radar DRS4D NXT
  • Network Radar DRS2D NXT
  • Network Radar DRS 12A/6A X Class
  • Network Radar DRS4DL+
  • Network Radar DRS4W

Standalone and Integrated Echo Sounders

  • Integrated echo sounder BBDS1
  • Integrated echo sounder DFF1-UHD
  • Integrated echo sounder DFF3-UHD
  • Multibeam integrated echo sounder DFF-3D

  • Standalone multibeam echo sounder WASSP
  • Standalone echo sounder FCV-1150

Other Sensors

  • FA-70

Control Panels

  • MCP-10
  • MCP-50

> CONTACT US ABOUT INTEGRATION OPTIONS


Chart plotter
MFD Radar, Kart, Echo sounder, Multibeam echo sounder
eI/O-120E CM interface modul

983000561
Furuno DRS 2D NXT

Compact solid-state network radar with display and operation through TimeZero Professional and NavNet. The DRSD2-NXT features a lightweight 48 cm enclosed antenna. Available functions are the same as for other DRS NXT models, including Target Analyzer™, RezBoost™, ATR – Auto Target Acquire, and FTT – Fast Target Tracking, as well as 2-range mode.

IMD040650AA
Furuno DRS 12A NXT

The DRS NXT is an award-winning series of solid-state (magnetron-free) network radars that can be integrated with TimeZero and NavNet. The DRS12A-NXT is a 100 W X-band radar with a range of 96 NM. It can be supplied with a 4- or 6-foot open antenna. It includes RezBoost™, Dual Range Mode, Fast Target Tracking, and Target Analyzer™, which utilizes the Doppler effect to analyze and present collision risks.

IMD040160AA-b
Furuno DRS 6A NXT

The DRS NXT is an award-winning series of solid-state (magnetron-free) network radars that can be integrated with TimeZero and NavNet. The DRS6A-NXT is a 25 W radar with a range of 72 NM. It can be supplied with a 4- or 6-foot open antenna. It includes RezBoost™, Dual Range Mode, Fast Target Tracking, and Target Analyzer™, which utilizes the Doppler effect to analyze and present collision risks.

IMD03658000-b
Furuno DRS 4D NXT

The DRS NXT is an award-winning series of solid-state (magnetron-free) network radars that can be integrated with TimeZero and NavNet. The DRS4D-NXT is a 25 W radar with a range of 48 NM. It is delivered with a 61 cm enclosed antenna. It includes RezBoost™, Dual Range Mode, Fast Target Tracking, and Target Analyzer™, which utilizes the Doppler effect to analyze and present collision risks.

IMD03456001-b
Furuno DRS 6A X-class

The DRS X-Class series replaces the DRS-4A and DRS-6A. An improved receiver and advanced signal processing provide crystal-clear echoes at both short and long distances. Lightning-fast target tracking of up to 30 vessels. New compact antenna.

IMD034550BB-b
Furuno DRS 4DL+

DRS 4DL+ has a compact 45 cm, 24 rpm radome antenna with UHD (Ultra High Definition) digital signal processing.

IMD03660001-b
Furuno Echosounder Module BBDS1

Dual frequency echosounder module with 50 kHz and 200 kHz center frequencies. Offers selectable 600 W/1 kW transmission power, bottom discrimination information in the echogram and ACCU-FISH™ fish size assessment in the water column. The availability of these features depends on transducer's supported functionality.

IMD03217001
Furuno Echosounder Module DFF1-UHD/A

Designed to operate at center frequencies of 50 kHz and 200 kHz. TruEcho CHIRP™ technology ensures noise-free presentation and excellent target separation. Provides clear imaging of the seabed and fish close to the bottom. Also offers fish size assessment in the water column. The availability of the ACCU-FISH™ function depends on the transducer.

IMD03356002
Furuno Echosounder Module DFF3-UHD

Powerful echo sounder module for NavNet TZT. Adjustable frequency between 25-242 kHz and selectable transmission power of 2 kW or 3 kW, depending on the transducer. Excellent range, noise-free presentation, and superior target separation.

IMD03481DAA
Furuno Multi-beam Echosounder DFF-3D

The DFF-3D features a 165 kHz multibeam transducer with 41 beams in a 120° fan shape, providing a detailed view of fish and bottom structures, intuitively presented in 3D. Echo sounder function with single or triple echogram display. Integrable with TimeZero Professional and NavNet TZT. With a compact transducer and easy installation, the DFF-3D is an excellent solution for coastal fishing vessels, smaller fishing boats, and workboats.

IMD03357000
Furuno Echosounder FCV-1150

The FCV-1150 is a compact echo sounder with adjustable frequency from 28-200 kHz and selectable 1/2/3 kW transmission power, depending on the transducer. It’s high-brightness color LCD with AR coated glass filter provides superior, glare-free viewing even in direct sunlight. Can be displayed and operated in TZTL/TZT and TimeZero.

IMD03007001
WASSP F3XLi System

WASSP F3X-L has a multibeam transducer with 224 beams in a 120-degree fan shape. Flexible software with "all" functions available. Radar and echo sounder presentation, side scanner, high-resolution depth presentation, bottom hardness, fish in the water column, etc. F3X-L has a frequency of 80 kHz and is suitable for larger fishing vessels operating in deep water. Integrable with MaxSea TimeZero.

WMB-6340F3XLi-080-20-b
WASSP F3Xi System

With WASSP F3X you get an accurate survey and information about the seabed, and you can quickly find the best fishing spots and save them for later use. Compact multibeam transducer with 224 beams in a 120-degree fan shape. Sonar and echo sounder presentation, side scanner, high-resolution depth presentation, bottom hardness, fish in the water column etc. Integrable with TimeZero Professional.

WMB-4340F3Xi-160-20-b
WASSP F3 for fishery 136-184 kHz (CHIRP)

WASSP F3 (136-184 kHz, CHIRP) provides precise surveying and seabed mapping. The multibeam transducer features 224 beams in a 120-degree fan shape. Flexible software with "all" functions available, including sonar and echo sounder display, side-scan, high-resolution depth presentation, bottom hardness, fish in the water column, and more. Integrable with TimeZero Professional.

IMD03661002-b
TimeZero Professional - Kontor

ms206010
