The Furuno FCV-38 is a powerful, fully stabilized echo sounder that utilizes both multi-beam and split-beam technology. Combined with a low operating frequency and high transmission power, the FCV-38 provides rich datasets, long detection range, excellent target discrimination, and effective noise filtering. Data export to NetCDF4 format is available. The transducer from the previous model, the FCV-30, can be reused for retrofit installations.

Powerful and feature-rich echo sounder with extremely high performance and functions for species identification and size distribution within fish schools. The recommended transducers include both high- and low-frequency elements and transmit on both frequencies simultaneously. The use of CHIRP technology ensures highly effective noise elimination. The recommended transducers enable the use of new IDENTI-FISH™ functions, which can present size distribution and potential species mixing within a school. Heave stabilization is achieved when connected to a satellite compass.

The FR-12 is a compact radar solution with a 12.1'' LCD color display and an integrated control panel for easy operation. The FR-12 can be combined with a selected Furuno DRS NXT or X-Class antenna (not included), providing the solution with high performance and modern features for safe navigation. The FR-12 is NMEA2000 certified, ensuring seamless integration with other relevant Furuno instruments such as the SCX-20/21 satellite compass and AIS FA-70.

TimeZero Professional is a professional plotter with all the necessary functions for navigation and fishing. The solution features full BarentsWatch integration, an outstanding weather forecast presentation with long-term predictions, and an overview of oceanographic data. It is integrable with Furuno radar, echo sounder, multibeam echo sounder, and sonar. Easy import of data from other chart systems.

X-band radar with 12 kW transmission power. Noise-free and accurate radar image. Aerodynamic antenna design reduces temperature peaks and wear on moving parts. Fanless and brushless antenna motor reduces maintenance needs. Approved for CAT 1, CAT 2, CAT 3, CAT 1H, and CAT 2H depending on screen choice. Also available in an NXT version (solid-state, magnetron-free).

TECDIS is an IMO-approved ECDIS, known for its exceptional user-friendliness. It features a highly efficient route planning and monitoring tool, with optional overlays such as radar and weather overlays, as well as AIO (ADMIRALTY Information Overlay). A TECDIS system consisting of two TECDIS units can be installed in compliance with paperless navigation requirements. Chart updates can be configured for online updating and an efficient one-click chart loading.

The NAVpilot-1000 is a type-approved and wheelmarked HSC (Heading Control System) that can be connected to both analog and solenoid steering systems. The pilot has both IMO mode, which meets the requirements of the performance standard, and non-IMO mode with functions outside the performance standard, which meets various operational needs.

The TS-332 is a stepping sonar that scans a desired sector of the trawl opening in a matter of seconds. The desired sector can be set within a full circle, and the step width can be set between 0.3 and 2.4 degrees. The TS-332 has an integrated dual-frequency 260 kHz/120 kHz echo sounder. The high frequency is well-suited for bottom trawling, while the low frequency is well-suited for pelagic trawling. Depth data from the trawl sonar can be exported and displayed on the echograms for the FCV-38 and FSS-3BB, as well as on the 3D Sonar F3D-S. Can be used with the Furuno Catch Sensor CS-400 and Marport catch sensors.
