Furuno Echosounder FCV-295

SKU: IMD02956001

EAN: IMD02956001

Stock:

Product name

Product number

First name

Last name

Telephone number

Comment

Would like to be contacted via Email Phone

Beskriv hva hendvendelsen gjelder og en av våre selgere vil deretter ta snarlig kontakt.

The FCV-295 is a compact fishing echo sounder with adjustable frequency from 28-200 kHz and selectable 1/2/3 kW transmission power, depending on the transducer. Excellent range and outstanding target separation. It features a bonded 10.4 LCD display providing superior viewing even in direct sunlight. You can display echoes in 8, 16, or 64 colors, with color assignment dependent on the strength of the returned echo.

Description
Specifications

Compact Echosounder with Adjustable Frequency

Selectable transmit power: 1 / 2 / 3 kW
Adjustable frequency range: 28–200 kHz
Excellent target separation
White line function
Rotary knob for gain control
Menu in Norwegian language available

COMPACT ECHOSOUNDER WITH ADJUSTABLE FREQUENCY

A compact sounder featuring adjustable frequency from 28 to 200 kHz as well as selectable transmit power of 1, 2, or 3 kW depending on the transducer. Delivers long range and excellent target separation.

Echo sounder
Frequency	28-200 kHz
Transmitter power	1 kW, 2 kW, 3 kW
Range (depending on transducer)	0-3000 m

Product details
Display	10,4'' 640x480 pixel
Power supply	12-24 VDC
Connections	NMEA 0183
Technology	FDF (Furuno Digital Filter), FFS - Selectable frequency

The standard set includes:

1 stk. Skjermenhet FCV-295-E
