Furuno Echosounder Module DFF1-UHD/A

SKU: IMD03356002

EAN: IMD03356002

Stock:

Product name

Product number

First name

Last name

Telephone number

Comment

Would like to be contacted via Email Phone

Beskriv hva hendvendelsen gjelder og en av våre selgere vil deretter ta snarlig kontakt.

Designed to operate at center frequencies of 50 kHz and 200 kHz. TruEcho CHIRP™ technology ensures noise-free presentation and excellent target separation. Provides clear imaging of the seabed and fish close to the bottom. Also offers fish size assessment in the water column. The availability of the ACCU-FISH™ function depends on the transducer.

Description
Specifications

Dual-Frequency CHIRP Echosounder Module

Center frequencies: 50 kHz and 200 kHz
1 kW output power
Crisp rendering of all echoes
Excellent target separation
ACCU-FISH™ (transducer dependent)
Bottom discrimination (transducer dependent)
Easy installation with network connection to plotter

CHIRP ECHOSOUNDER MODULE

Echosounder module with center frequencies of 50 kHz and 200 kHz. CHIRP technology ensures noise-free imaging and excellent target separation. Clear bottom definition and detection of fish close to the seabed. Also delivers good separation between different types of fish in the water column. Depending on the transducer, functions such as bottom discrimination and ACCU-FISH™ are available.

Echo sounder
Technology	CHIRP
Frequency	50 kHz, 200 kHz
Transmitter power	600 W, 1 kW
Range (depending on transducer)	2-1200 m

Product details
Power supply	12-24 VDC
Connections	LAN TZ/NavNet

The standard set includes:

1 stk. DFF1-UHD-E IP55
