Furuno Radar FAR-1513, 24 VDC

SKU: IMD03468000-b
EAN: IMD03468000
Stock:

Coastal radar ideally suited for vessels not requiring IMO approval. The ACE (Automatic Clutter Elimination) noise reduction function filters out noise and false echoes. Fast Target Tracking locks onto targets and presents their speed and course within just a few seconds. Both the 50-target ARPA module and AIS module with up to 300 targets (when AIS is connected) are included as standard equipment. FAR-1513 also features the Target Analyzer function, which highlights moving targets approaching the vessel in a different color than stationary echoes such as islets or rocks.

X-band radar with noise-free presentation

  • 12 kW output power
  • 4 ft. or 6 ft. open antenna with beamwidths of 1.35 and 1.9 degrees respectively
  • Target Analyzer displays moving targets, rain, and sea clutter in different colors
  • Target Tracking provides fast and accurate echo acquisition
  • Noise reduction function (ACE) effectively filters out false echoes
  • AIS display included as standard
  • Compact control unit, can be complemented with trackball RCU-30

X-band radar FAR-1513 (12 kW)

Coastal radar ideally suited for vessels not requiring IMO approval.

The ACE (Automatic Clutter Elimination) noise reduction function filters out noise and false echoes. Fast Target Tracking locks onto targets and presents their speed and course within just a few seconds. Both the 50-target ARPA module and AIS module with up to 300 targets (when AIS is connected) are included as standard equipment.

FAR-1513 also features the Target Analyzer function, which highlights moving targets approaching the vessel in a different color than stationary echoes such as islets or rocks.



Radar
Radar band X-band (3 cm)
Transmitter power 12 kW
Temp. interval -25 - +55 °C
RPM 24
Radar type Magnetron
Product details
Display Selectable size, addon
The standard set includes:
