Furuno Chart Radar FAR-3025
SKU:
IMD0407203A-b
EAN: IMD0407203AX-band (3 cm) chart radar with 25 kW transmission power. The antenna unit is designed for minimal wear and features a brushless motor. This model can be used as a standalone radar or configured as a Multi-Function Display (MFD) and integrated as a workstation in the Furuno Voyager INS. Compatible with Furuno oil, ice, and wave radar.
| Radar | |
|---|---|
| Series | FAR-30xx |
| Radar band | X-band (3 cm) |
| Scanner size | 6,5 ft |
| Transmitter power | 25 kW |
| Temp. interval | -25 - +55 °C |
| RPM | 24, 42 |
| Radar type | Magnetron, Chart radar |
| Addon radar | Oil radar, Ice radar, Wave radar |
| Functions | Shuttle ferry mode, Backup for ECDIS |
| Product details | |
|---|---|
| Display | Selectable type approval monitor, addon |
| Power supply | 220-240 VAC 50Hz |
| Connections | LAN, RS-422 |
| Approval/Class | IMO/MED, IMO/MER, NAUT-AW, NAUT-OSV, CAT 1C, CAT 2C, CAT 1HC, CAT 2HC |
The standard set includes:
1 stk.
Strømforsyning PSU-014
1 stk.
Gearboks RSB-146-132N
