Night Navigator 2015 Electro-Optical Infrared System Dome Up
Produktnummer:
NN2015-U
The Night Navigator 2015 integrates an LWIR uncooled thermal imager and a high definition (HD) day camera/low light in a gyro-stabilized sensor platform.
| Termisk kamera | |
|---|---|
| Infrared Sensor | Uncooled |
| Spectral Range | 8 - 12 µm |
| Sensor Type | LWIR (Long Wave Infrared) |
| Resolution | 640x512 pixels |
| Field of View | 18 ° |
| Digital Zoom | 4 x |
| F Stop | f/1.2 |
| IR Detection Range - Human (1.8x0.5 m) | 0.9 km |
| IR Detection Range - NATO (2.3x2.3 m) | 2.3 km |
| Detection Range | Short-Range (≤ 5 km) |
| Kamera | |
|---|---|
| Sensor Type | HD Day / Low Light |
| Resolution | 1920x1080 pixels |
| Field of View | 64 - 2.4 ° |
| Continuous Optical Zoom | 30 x |
| Continuous Digital Zoom | 12 x |
| Low Light sensitivity in black and white mode | 0,00008 lux |
| Produktdetaljer | |
|---|---|
| Strømforsyning | 24-36 VDC |
| Power Max Consumption | 210 W |
